2D Barcodes2D : PDF417, MicroPDF417, GS1 Composite ,
Code11, Aztec Code, Data Matrix, QR Code, Micro
QR Code, MaxiCode, Han Xin Code, DOT Code
OCR: OCR-A, OCR-B, E13B (MICR)
PostalIntelligent Mail Barcode, Postal-4i, Australian
Post, Japanese Post, Netherlands (KIX) Post,
Postnet, Planet Code
RFID
UHF RFIDFrequency: 865~868MHz, 902~928MHz
Protocol: EPC global Class 1 Gen 2 ISO 18000-6C/6B
Antenna gain: 4dbi
Output Power : 1-30dbm adjustable
Data Capture Range: 6~8 meters
HF RFIDSupport HF/NFC
Frequency 13.56Mhz
Support: ISO14443A/B, ISO15693 standard
I/O Interfaces
USBUSB 3.1 (type-C) support USB OTG
Support Display Port Mode
Ethernet/USB-Host via cradle
OTGYes, over USB Type-C
POGO PINCustom IO connector (include USB Host)
SIM SlotNano SIM Slot x 2
Expansion SlotMicro SD/TF x 1(Support SD, SDHC and SDXC) up to 256GB
Audio2W output, One speaker with Smart PA (105 dB at 10cm),
Dual-Microphone, support noise cancellation
MDM SoftwareSOTI, AirWatch, 42Gears, Ivanti Wavelink, and MoboLink
Enclosure
Dimensions ( W x H x D )195 mm x 72 mm x 34 mm
Weight395g(with battery)
Durability
Drop Specification1.8m / 2.4m(with Bumper)
SealingIP65 / IP67
Tumble testTumble 600 times (1.6 ft./0.5 m)
Environmental
Operating temperature-20°C to +50°C
Storage temperature- 30°C to 70°C (without battery)
Charging temperature0°C to 45°C
Relative Humidity5% ~ 95% (non-condensing)
Accessories
Accessories■ Battery 3.7V 6700mAh (PN#1400-900071G)
■ Hand Strap (PN#608909G)
■ USB 3.0 type-C Cable(PN#1550-905908G)
■ Power Adaptor(PN#1010-900061G(US) PN#1010-900062G(EU) PN#1010-900063G(CN)
■ Single Slot Charging Cradle (PN#5000-900086G)
■ Single Slot USB Cradle (PN#5000-900090G)
■ Single Slot Ethernet Cradle (PN#5000-900087G)
■ Single Slot Display Port Cradle (PN#5000-900088G)
■ 5V/6A Power Supply for 1-slot Cradle (PN# 1010-900043G)
■ 3-Pin Power Cord (UK) PN#1550-602689G
■ 3-Pin Power Cord(EU)PN#1550-602333G
■ 3-Pin Power Cord(US)PN#1010-601551G
■ Standard Gun Grip (PN# 5500-900096G)
■ 4-Slot Charging Cradle(PN#5000-900089G)
■ 4-Slot Ethernet Cradle(PN#5000-900091G)
■ 4-Slot battery Charger (PN# 5100-900031G)
■ 12V/5A Power Supply for 4-slot Cradle (PN#1010-900068G)
■ Glass Screen Protector(PN#401609G)
■ Stylus with Coil Strap (PN# 1979-900003G)
■ HT730 Bumper Package for Standard Range Engine (PN#5400-900048G)
■ HT730 Bumper Package for Long Range Engine (PN#5400-900049)
■ HT730 Boot case for Standard Range Engine (PN#3210-900036G)
■ RP902 Bluetooth UHF RFID Pocket Reader (PN#RP902-33E8S0G (EU), PN#RP902-43A8S0G (US), PN#RP902-43F8S0G (JP))
■ Quick charge UK USB Plug (PN#1010-51C002G)
■ Quick charge EU USB Plug (PN#1010-51C001G)
■ HT730 Battery Cover (PN#386108G)
What comes in the box
The basic package contents■ HT730 Terminal
■ Battery
■ Hand Strap
StatementThis product is warranted against defects in workmanship and materials for a period of twelve months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information.
